At Value Crane, we take pride in offering a wide selection of high-quality manual hoist that meet your lifting needs with precision and reliability. Our range of manual hoists is carefully chosen to ensure durability, safety, and optimal performance in various applications.
Whether you require a hand chain hoist or a manual hoist trolley, we have you covered. Our products are sourced from reputable manufacturers known for their commitment to excellence and adherence to stringent quality standards.
crawler crane hand chain hoist
A hand chain hoist, also known as a manual chain hoist, is a versatile and durable lifting device. Encased in a sturdy steel housing, it consists of a chain mechanism and a load-bearing hook. By pulling the hand chain, operators engage the mechanism, enabling controlled vertical lifting. Hand chain hoists are compact, portable, and commonly used in construction, manufacturing, and warehouse applications. They are available in various load capacities, designed to withstand demanding conditions. Safety is paramount when operating hand chain hoists, requiring adherence to proper lifting techniques and load limits. With their cost-effectiveness and reliability, hand chain hoists are indispensable tools for efficient lifting across industries.
HSZ chain hoist
- Certifications:TUV-CS, TUV-GS
- Capacity: 0.5-30t
- Load Chain Material:grade 80 alloy steel
The HSZ chain hoist is a reliable and durable lifting device, widely used in various industrial applications. With its robust construction and versatile load capacities, it ensures precise and controlled lifting operations. Featuring a compact and lightweight design, it is portable and suitable for tight spaces.
The Parameters Of HSZ Chain Hoist
Model | Capacity/t | Lifting Height Standard/mm | Test Load/t | Min Distance (Hook To Hook)/mm | Chain Pull To lift Fulload/N | Diameter Of Load Chain/mm | No. Of Load Chain Fallines | Dimensions/mm | |
A | B | ||||||||
HSZ-0.5 | 0.5 | 2.5 | 0.75 | 270 | 225 | 6 | 1 | 120 | 108 |
HSZ-1 | 1 | 2.5 | 1.5 | 270 | 309 | 6 | 1 | 142 | 122 |
HSZ-1.5 | 1.5 | 2.5 | 2.25 | 368 | 343 | 8 | 1 | 178 | 139 |
HSZ-2 | 2 | 2.5 | 3 | 444 | 314 | 6 | 2 | 142 | 122 |
HSZ-3 | 3 | 3 | 4.5 | 486 | 343 | 8 | 2 | 178 | 139 |
HSZ-5 | 5 | 3 | 7.5 | 616 | 383 | 10 | 2 | 210 | 162 |
HSZ-10 | 10 | 3 | 12.5 | 700 | 392 | 10 | 4 | 358 | 162 |
HSZ-20 | 20 | 3 | 25 | 1000 | 392 | 10 | 8 | 580 | 189 |
HSH chain hoist
- Type:chain block lever hoist
- Gear:two stage gear
- Certifications:TUV-CS, TUV-GS
Introducing the HSH chain hoist, a versatile lifting solution designed for various industrial applications. With its innovative design and advanced features, the HSH chain hoist offers flexibility and performance for both vertical and horizontal lifting operations. Built with durability in mind, it features a compact and low headroom design for use in tight spaces. The HSH chain hoist provides smooth and precise lifting with its high-quality chain mechanism and ensures safety with overload protection and reliable braking systems. Elevate your lifting operations with the reliable and efficient HSH chain hoist.
The Parameters Of HSH Chain Hoist
Capacity/t | Chain Length/m | Load Chain/mm | Max Lifting Effort/H | Pulley Block Multiplicity | Weight/kg |
0.5 | 3-12 | 6*18 | 130 | 1 | 9 |
0.75 | 3-12 | 6*18 | 148 | 1 | 9 |
1 | 3-12 | 6*18 | 180 | 1 | 9 |
1.5 | 3-12 | 8*24 | 200 | 1 | 11.5 |
2 | 3-12 | 8*24 | 216 | 1 | 12.6 |
3 | 3-12 | 10*29 | 336 | 1 | 22 |
6 | 3-12 | 10*30 | 345 | 2 | 37 |
9 | 3-12 | 10*30 | 370 | 3 | 47 |
manual hoist trolley
Introducing the manual hoist trolley, a versatile and practical solution for moving heavy loads with ease. Designed to work in conjunction with manual chain hoists, the manual hoist trolley offers enhanced mobility and flexibility in various industrial settings.
With its sturdy construction and durable components, the manual hoist trolley provides reliable support and stability during material handling operations. It features a robust frame equipped with wheels or rollers, allowing for effortless movement along beams or tracks.
TP trolley
- Type:plain/push trolley
- Capacity:0.5-10t
- Operating temperature:-30°C-100°C
- Certification:2006/42/EC
- Bar configuration:single/twin
TP (Plain/Push) trolleys are manually operated tools used in diverse industries. They have a simple design with minimal moving parts, making them easy to use and maintain. These compact and lightweight trolleys are portable and suitable for tight spaces. They offer a cost-effective solution for basic load movement, making them accessible for various applications. TP trolleys are compatible with different beam types and sizes, providing flexibility in different work environments. While they may lack advanced safety features, it is important to follow proper safety protocols when operating them. Overall, TP trolleys are practical, affordable, and versatile tools for manual load movement in warehouses, workshops, factories, and construction sites.
The Parameters Of TP Trolley
Type | Code/t | Capacity/t | Track Width | Dimensions/mm | Min Curve Ratio/m | Net Weight/kg | ||||||||||
Range 1/mm | Range 2/mm | A | A+ | B | C | E | F | G | H | J | K | |||||
Single Bar Trolleys | TPS-0050 | 0.5 | 62-128 | 62-203 | 195 | 235 | 106 | 106 | 98 | 20 | 64 | 10 | 24 | 30 | 0.8 | 5.0 |
TPS-0100 | 1.0 | 62-128 | 62-203 | 213 | 253 | 113 | 113 | 106 | 20 | 71 | 10 | 27 | 34 | 1.0 | 7.5 | |
TPS-010W | 1.0 | 106-305 | N/A | 236 | 284 | 210 | 210 | 132 | 25 | 80 | 13 | 38 | 45 | 1.3 | TBA | |
TPS-0200 | 2.0 | 88-154 | 88-230 | 236 | 284 | 136 | 136 | 132 | 25 | 80 | 13 | 38 | 45 | 1.3 | 12.0 | |
TPS-0300 | 3.0 | 87-153 | 88-230 | 275 | 323 | 146 | 146 | 150 | 25 | 97 | 13 | 42 | 53 | 1.5 | 19.5 | |
TPS-0500 | 5.0 | 106-194 | 106-305 | 323 | 371 | 169 | 169 | 174 | 30 | 117 | 16 | 46 | 59 | 1.5 | 30.5 | |
Twin Bar Trolleys | TPT-0300 | 3.0 | 87-153 | 88-230 | 320 | 368 | 142 | 142 | 82 | 16 | 110 | 1.5 | 22.0 | |||
TPT-0500 | 5.0 | 10-194 | 106-305 | 352 | 400 | 167 | 167 | 91 | 24 | 131 | 1.5 | 35.5 | ||||
TPT-1000+ | 10.0 | 125-320 | N/A | 346 | 394 | 237 | 237 | 210 | 40 | 117 | 1.5 | 68 | ||||
TPT-1500+ | 15.0 | 150-320 | N/A | 461 | 509 | 271 | 271 | 248 | 42 | 182 | 2.7 | 144.0 | ||||
TG trolley
- Type:geared trolley
- Capacity:0.5-30t
- Bar configuration:single/twin
TG (Geared) trolleys are manual load movement tools known for their advanced features. With a capacity range of 0.5 to 30 tons, they can handle a wide variety of loads.
Featuring a geared mechanism, TG trolleys provide precise control over speed and direction. This allows for accurate load positioning, crucial for applications requiring precision.
Available in single or twin bar configurations, TG trolleys offer flexibility. Single bar trolleys are compact and lightweight, ideal for smaller loads and limited spaces. Twin bar trolleys provide enhanced stability and load-bearing capacity, distributing the load across two points of contact.
The Parameters Of TG Trolleys
Type | Code | Capacity/t | Track Width | Dimensions/mm | Min Curve Ratio/mm | Net Weight/Kg | ||||||||||
Range 1/mm | Range 2/mm | A | A+ | B | C | E | F | G | H | J | K | |||||
Single Bar Trolleys | TGS-0050 | 0.5 | 62-128 | 62-203 | 195 | 235 | 180 | 106 | 98 | 20 | 64 | 10 | 24 | 30 | 0.8 | 9.0 |
TGS-0100 | 1.0 | 62-128 | 62-203 | 213 | 253 | 180 | 113 | 106 | 20 | 71 | 10 | 28 | 34 | 1.0 | 11.0 | |
TGS-010W | 1.0 | 106-305 | N/A | 236 | 284 | 269 | 210 | 132 | 25 | 80 | 12 | 38 | 45 | 1.3 | TBA | |
TGS-0200 | 2.0 | 88-154 | 88-230 | 236 | 284 | 193 | 136 | 132 | 25 | 80 | 12 | 38 | 45 | 1.3 | 16.5 | |
TGS-0300 | 3.0 | 87-153 | 87-230 | 275 | 323 | 198 | 146 | 150 | 25 | 97 | 13 | 42 | 52 | 1.5 | 24.5 | |
TGS-0500 | 5.0 | 106-194 | 106-305 | 323 | 371 | 216 | 169 | 174 | 30 | 117 | 16 | 46 | 60 | 1.5 | 35.5 | |
Twin Bar Trolleys | TGT-0300 | 3.0 | 87-153 | N/A | 320 | 368 | 194 | 142 | 82 | 16 | 110 | 1.5 | 23.5 | |||
TGT-0500 | 5.0 | 106-194 | N/A | 352 | 400 | 216 | 166 | 91 | 24 | 131 | 1.5 | 40.0 | ||||
TGT-1000+ | 10.0 | 125-320 | N/A | 346 | 394 | 282 | 243 | 210 | 40 | 117 | 1.5 | 78.0 | ||||
TGT-1500+ | 15.0 | 150-320 | N/A | 461 | 509 | 338 | 271 | 248 | 42 | 182 | 2.7 | 161.0 | ||||
TGT-2000+ | 20.0 | 125-320 | N/A | 706 | 754 | 282 | 263 | 243 | 40 | 117 | 30 | 85 | 95 | 6.0 | 160.0 | |
TGT-2500+ | 25.0 | 125-320 | N/A | 706 | 754 | 282 | 263 | 243 | 40 | 117 | 35 | 100 | 115 | 6.0 | 170.0 | |
TGT-3000+ | 30.0 | 150-320 | N/A | 961 | 1009 | 335 | 263 | 274 | 42 | 182 | 35 | 100 | 115 | 6.0 | 337.0 | |
TGT-3500+ | 35.0 | 150-320 | N/A | 961 | 1009 | 335 | 280 | 274 | 42 | 182 | 38 | 100 | 115 | 6.0 | 341.0 | |
Conclusion
In conclusion, manual hoists are reliable, cost-effective tools for lifting and moving loads. They offer versatility, durability, and direct control to operators. Despite requiring physical effort, manual hoists provide precise load control and can be used in various environments. With proper maintenance and adherence to safety guidelines, they prove to be valuable assets in industries such as construction, warehousing, and workshops. Manual hoists are an essential component of manual material handling operations, providing an efficient solution for lifting tasks.
